Total Cloud Fraction Variable Comparison
report produced with glance, version 0.3.3
analysis generated Thu Jun 29 16:42:47 2017 by user wstraka on kanchi.ssec.wisc.edu
file A:
path: /data/temp/CCL_TRR/CloudHeightAlgorithm_20170528_1830_41_000000_1.h5
md5sum for file A: 82ee348e792c8788a18e981bc01ae8f0
last modified: Wed Jun 28 18:10:54 2017
file B:
path: /data/temp/CCL_TRR/GOESR_ABI_FD_2017148_1830_00_CLOUD_HEIGHT_BL.nc
md5sum for file B: 9e21f1bc3739742cc0d9e2f7247509ff
last modified: Tue Jun 27 17:05:35 2017
A configuration file was used to control the production of this report.
Please see this copy of the configuration file
for details.
Note: The data for this variable from file A was filtered.
Original Data
Comparison Information
variable name in A: ACH::CloudFraction::SFC_TOA::Two_km
variable name in B: Total_Cloud_Fraction
epsilon value: 0.0
"missing" data value: -999.0
units in B: 1
Statistical Summary
-
Finite Data Statistics
-
a_finite_count*: 20195237
a_finite_fraction*: 0.6865
b_finite_count*: 23046258
b_finite_fraction*: 0.7834
common_finite_count*: 20184411
common_finite_fraction*: 0.6861
finite_in_only_one_count*: 2872673
finite_in_only_one_fraction*: 0.09764
-
-
General Statistics
-
a_missing_value*: -999.0
b_missing_value*: -999.0
epsilon*: 0.000
epsilon_percent*: None
max_a*: 1.000
max_b*: 1.000
mean_a*: 0.6735
mean_b*: 0.5901
median_a*: 0.9600
median_b*: 0.8400
min_a*: 0.000
min_b*: 0.000
num_data_points*: 29419776
shape*: (5424, 5424)
spatially_invalid_pts_ignored_a*: 0
spatially_invalid_pts_ignored_b*: 0
std_val_a*: 0.3814
std_val_b*: 0.4390
-
-
Missing Value Statistics
-
a_missing_count*: 9224539
a_missing_fraction*: 0.3135
b_missing_count*: 6373518
b_missing_fraction*: 0.2166
common_missing_count*: 6362692
common_missing_fraction*: 0.2163
-
-
NaN Statistics
-
a_nan_count*: 0
a_nan_fraction*: 0.000
b_nan_count*: 0
b_nan_fraction*: 0.000
common_nan_count*: 0
common_nan_fraction*: 0.000
-
-
Numerical Comparison Statistics
-
correlation*: 0.9872
diff_outside_epsilon_count*: 6784207
diff_outside_epsilon_fraction*: 0.3361
max_delta*: 0.6800
max_diff*: 1.000
mean_delta*: -0.0004838
mean_diff*: 0.03710
median_delta*: 0.000
median_diff*: 0.000
min_delta*: -1.000
mismatch_points_count*: 9656880
mismatch_points_fraction*: 0.3282
perfect_match_count*: 13400204
perfect_match_fraction*: 0.6639
r-squared correlation*: 0.9745
rms_val*: 0.07562
std_val*: 0.07564
-
