The Profiler Station Plot display shows winds at one level above one or more stations on the Main Display window. Winds are shown with the wind barb symbol. For more information on what wind speeds correspond to each of the wind barbs in McIDAS-V displays, please see the table in the FAQ.

Image 1: Profiler 3D Multi-station Controls

• Color Table - Shows the active color table and the associated high and low data values in the units of the display. As the mouse pointer is moved over the color bar, the value at a particular color is shown. Right click on the color bar or click on the button that displays the name of the Color Table to make modifications to the color bar. This allows you to open the Color Table Editor, change the range, select other color tables, etc.
• Windbarb size - Sets the size of the wind barbs displayed in the Main Display window.
• Plan level - Changes the level above mean sea level, in meters, where the wind barbs are plotted.

All of the menu items seen utilizing this display are standard options that can be found in the Menus section of the Layer Controls page.
